Product Details:
Place of Origin: China
Brand Name: LION KING
Payment & Shipping Terms:
Minimum Order Quantity: 2 pieces
Price: $350.00/pieces >=2 pieces
Packaging Details: plywood case <br>1) EFC120X 16'' : 49*36.5*50cm G/N.:30/26 Kgs <br>2) EFC120X 20'' : 66*47*80cm G/N.:52/38 Kgs <br>3) EFC120X 24'' : 73*50*90cm G/N.:59/45 Kgs
Supply Ability: 100 Set/Sets per Week

smoke exhaust fan,smoke ejectors,PPV fans

Description
Applicable Industries: Hotels, Garment Shops, Building Material Shops Customized Support: OEM, ODM
Electric Current Type: AC Blade Material: Cast Iron
Mounting: FREE STANDING Voltage: 220V/380V
Warranty: 1 Year After-sales Service Provided: Online Support, No Overseas Service Provided
Function: Smoke Exhaust Motor: 1.1KW For 16", 1.2KW For 20",1.5KW For 24"
Material: Anti-static Glass Reinforced ABS Housing Type: Centrifugal Fan
Port: Ningbo Or Shanghai Port

LION KING high performance fans are powerful and reliable, used in a variety of scenarios

and can quickly provide clear visibility for fire fighters and rescue forces,

remove smoke from escape routes,and lower temperatures,especially in complex building

or in case of extreme smoke formation

Specification of EFC120X Series ( 3 Series available)



1)  EFC120X  16'' : 6482~10360m3/h; 2900rpm; 17-blades; impeller size:400mm;

2)  EFC120X  20'' : 8000~16150m3/h; 1450rpm; 9-blades; impeller size:500mm;

3)  EFC120X  24'' : 10264~18360m3/h; 1450rpm; 9-blades; impeller size:600mm;

Feature:
1.Sackable for additional easy storage
2.High strength,anti-static glass reinforced ABS housing is lightweight,corrosion proof and chemical resistant
3.Optional duct adapter for use in confined space applications;
4.Available with in various voltage and frequency configuration;
5.Optional door bar and hanger kit for suspending in doorways windows.



Application:

Widely used for ventilation at factory building,warehouses,construction sites,tunnel,mining area.also can be used for firefighting
