Product Details:
|
| Applicable Industries: | Hotels, Building Material Shops, Manufacturing Plant, Food & Beverage Factory, Restaurant, Home Use, Food Shop, Printing Shops, Advertising Company | Electric Current Type: | AC |
|---|---|---|---|
| Blade Material: | Galvanized Steel Sheet | Mounting: | FREE STANDING |
| Voltage: | 380V | Warranty: | 1 Year |
| After-sales Service Provided: | Online Support, No Overseas Service Provided | Motor Type: | AC Copper Motor |
| Frequency: | 50,60hz | Type: | Centrifugal Fan |
Impeller Diameter | 200-450mm |
Air Volume Range | 1000-40000m³/h |
Total Pressure Range | 140-1000Pa |
Sound Range | 60-90dB(A) |
Dirve Type | Belt Drive |
Model | 7-7,8-8,9-7,9-9,10-8,10-10,12-12,15-15,18-13,18-18 |
